Premium Industrial
Steel Belt
High-strength, temperature-resistant steel belts engineered for continuous condensation and flaking systems. Made with premium imported materials for maximum durability and precision.
Structural Features & Function
Advanced Engineering
Advanced Bonding Process: Two European standard vulcanized rubber strips are bonded on the back, with a bottom width of 20mm and a height of 17mm. The bonding process is highly advanced, ensuring reliable strength and a long service life under demanding industrial conditions.
Primary Function: Expertly designed to bear, condense, solidify, and convey molten sulfur. It operates seamlessly in conjunction with the cooling system to realize rapid and consistent product forming.
Technical Specifications & Control
Model & Dimensions
Supporting steel belt for YCF1500-3 (13m) sulfur granulator. Dimensions are 26690 × 1500 × 1mm, manufactured with strict tolerances (width ±1mm, thickness ±0.05mm) for precise operation.
Premium Material
Manufactured using imported chemical-grade stainless steel from IMPAXX (Sweden). It features exceptional strength, hardness, and toughness, along with high temperature and corrosion resistance.
Drive System
Powered by a direct-connected reducer located at the tail of the machine. It utilizes variable frequency speed regulation to ensure smooth, adjustable, and continuous running performance.
Safety & Control
Equipped with a highly responsive automatic deviation alarm device. This critical matching system continuously monitors alignment to ensure stable operation and prevent equipment damage.
